LC/SC/ST TYPE PATCHCORDS

Features

  • Connector options: LC, SC types
  • Simplex or Duplex available
  • Choice of cable color and length
  • LSZH cable jacket

Applications

  • CATV
  • Data processing networks
  • Telecommunication networks
  • WANs and LANs
Specification:

Type

Insertion Loss

Return Loss

Repeatability

Durability

Interchange-ability

Tensile Strength

Operating Temperature(℃)

LC/SC/ST
Patch cord
(SMF)

IL ≤ 0.3dB

≥ 50dB (UPC)
≥ 60dB (APC)

≤ 0.1

≤ 0.2dB
typical chang 1000 Matings

≤ 0.2dB

>10kg

-40 ~ 85

LC/SC/ST
Patch cord
(MMF)

IL ≤ 0.3dB

≥ 30dB

≤ 0.1

≤ 0.2dB
typical chang 1000 Matings

≤ 0.2dB

>10kg

-40 ~ 85

Ordering Information:
1 Connector A 2 Connector B 3 Fiber Mode 4 Fiber
Count		 Length 5 Fiber Diameter
Polarity		 6 Jacket
         LC=LC/UPC          LC=LC/UPC     OS2=Single Mode 9µm          S=Simplex           1M=1meter          09=0.9mm          PV=PVC
       LCA=LC/APC        LCA=LC/APC   OM2=OM2 50µm        D=Duplex        2M=2meter        20=2.0mm        LS=LSZH
       SC=SC/UPC        SC=SC/UPC   OM3=10G OM3 50µm          3M=3meter        30=3.0mm        OP=OFNP
       SCA=SC/APC        SCA=SC/APC   OM4=10G OM4 50µm          4M=4meter
       ST=ST/UPC        ST=ST/UPC            ......
       STA=ST/APC        STA=ST/APC            xxM=xxmeter
