MPO/MPT TYPE PATCHCORD
Features
- Connector options: MPO, LC types
- 8 or 12 core available
- Choice of cable color and length
- LSZH cable jacket
Applications
- CATV
- Data processing networks
- Telecommunication networks
- WANs and LANs
Specification:
Ordering Information:
| Type | Insertion Loss | Return Loss | Repeatability | Durability | Interchange-ability | Tensile Strength | Operating Temperature(℃) |
| MPO Patch cord | IL ≤ 0.35dB | ≥60dB | ≤0.1 | ≤0.2dB | ≤0.2dB | >10kg | -40 ~ 85 |
| MPO Patch cord | IL≤0.35dB | ≥25dB | ≤0.1 | ≤0.2dB | ≤0.2dB | >10kg | -40 ~ 85 |
Ordering Information:
| 1 | 2 | Connector A | 3 | Connector B | 4 | Length | 5 | Pinout Schematic | 6 | Fiber Mode |
| C | MPO=MTP/UPC 12 Fiber Female | MPO=MTP/UPC 12 Fiber Female | 1M=1meter | Type A= Straight Through | OS2=9/125μm Single Mode | |||||
| MPOA=MTP/APC 12 Fiber Female | MPOA=MTP/APC 12 Fiber Female | 2M=2meter | Type B= Cross | OM3=50/125µm Multi Mode | ||||||
| 3M=3meter | Type C= Cross Pair | OM4=50/125µm Multi Mode | ||||||||
| 4M=4meter | ||||||||||
| ...... | ||||||||||
| xxM=xxmeter |
