Optical Transceiver

10G SFP+ Bidi Series

Features

  • SFP+ Bidi Transceiver series
  • LC optical connector
  • Dual Wavelength (WDM) Bidirectional Transmission
  • +3.3V power supply
  • Hot Pluggable
  • Compliant to SFP+ MSA
  • Compliant with SFF-8472 MSA Digital Diagnostic Monitor (DDM)
  • RoHS Compliant

Applications

  • 10GBASE Ethernet
  • High speed I/O for file server
  • Mass storage system I/O
  • Bus extension application

Part Number Application Datarate Wavelength Media Distance Tx Power Rx Sens Temp Data Sheet
SFP+-B23-D2-N SFP+ 10G Bidi 1270nm 10.3125Gb/s 1270nm SMF 20KM -2.0~+2.0 -14.5 0~+70 Press to contact us
SFP+-B32-D2-N SFP+ 10G Bidi 1330nm 10.3125Gb/s 1330nm SMF 20KM -2.0~+2.0 -14.5 0~+70 Press to contact us
SFP+-B23-D3-N SFP+ 10G Bidi 1270nm 10.3125Gb/s 1270nm SMF 40KM 0.0~+5.0 -15.5 0~+70 Press to contact us
SFP+-B32-D3-N SFP+ 10G Bidi 1330nm 10.3125Gb/s 1330nm SMF 40KM 0.0~+5.0 -15.5 0~+70 Press to contact us
SFP+-B23-D4-N SFP+ 10G Bidi 1270nm 10.3125Gb/s 1270nm SMF 60KM +1.5~+6.0 -21.0 0~+70 Press to contact us
SFP+-B32-D4-N SFP+ 10G Bidi 1330nm 10.3125Gb/s 1330nm SMF 60KM +1.5~+6.0 -21.0 0~+70 Press to contact us
SFP+-B45-D5-N SFP+ 10G Bidi 1490nm 10.3125Gb/s 1490nm SMF 80KM 0.0~+4.0 -23.0 0~+70 Press to contact us
SFP+-B54-D5-N SFP+ 10G Bidi 1550nm 10.3125Gb/s 1550nm SMF 80KM 0.0~+4.0 -23.0 0~+70 Press to contact us
