100G QSFP28 Bidi Series PAM4
Features
- QSFP28 Bidi Transceiver series
- LC optical connector
- Dual Wavelength (WDM) Bidirectional Transmission
- Up to 106.25Gbit/s PAM4 data links
- +3.3V power supply
- Hot Pluggable
- Compliant to SFF-8636 QSFP28 MSA
- RoHS6 compliant
Applications
- 100GBASE Ethernet
| Part Number | Application | Datarate | Wavelength | Media | Distance | Tx Power | Rx Sens | Temp | Data Sheet |
| QSFP28-B23-D1-N | QSFP28 Bidi Tx1270nm/ Rx1330nm 10km | 100Gb/s | 1270nm | SMF | 10KM | -1.9~4.8 | -6.1 | 0~+70 | Press to contact us |
| QSFP28-B32-D1-N | QSFP28 Bidi Tx1330nm/ Rx1270nm 10km | 100Gb/s | 1330nm | SMF | 10KM | -1.9~4.8 | -6.1 | 0~+70 | Press to contact us |
| QSFP28-B49-D2-N | QSFP28 Bidi Tx1304.6nm/ Rx1309.1nm 20km | 100Gb/s | 1304nm | SMF | 20KM | -0.2~6.6 | -7.6 | 0~+70 | Press to contact us |
| QSFP28-B94-D2-N | QSFP28 Bidi Tx1309.1nm/ Rx1304.6nm 20km | 100Gb/s | 1309nm | SMF | 20KM | -0.2~6.6 | -7.6 | 0~+70 | Press to contact us |
| QSFP28-B49-D3-N | QSFP28 Bidi BR Upstream 40km | 100Gb/s | 1304nm | SMF | 40KM | 1.7~7.1 | -13.8 | 0~+70 | Press to contact us |
| QSFP28-B94-D3-N | QSFP28 Bidi BR Downstream 40km | 100Gb/s | 1309nm | SMF | 40KM | 1.7~7.1 | -13.8 | 0~+70 | Press to contact us |
